Basic Operation
• The voltage, current, power setting values displayed on the main interface
when the instrument is powered on.
• Parameter setting values in the Config menu.
• The output state of the power supply, i.e., the [On/Off] key state.
The procedures to set the menu item are as follows.
1. Press the composite keys [Shift]+[P-set] (System) on the front panel to en-
ter the system menu.
2. Press the Up/Down key or turn the knob to select the PowerOn and press
[Enter].
3. Press the Left / Right key or turn the knob to adjust the value of this
parameter.
• Reset: Default value, indicates when the instrument is powered on, the
instrument will initialize some parameter settings or state.
The affected parameters and the reset information are as shown in the
following table.
Table 5–1 Initial value of the parameter
Category
Parameter Initial Value
Main
interface
Voltage setting: Vs One percent of the
rated voltage of the
instrument
Current setting: Is One percent of the
rated current of the
instrument
Upper limit of voltage: Vh, and
lower limit of voltage: Vl
Upper limit value: One
percent of the rated
voltage of the
instrument
Lower limit value: 0
Upper limit of current: I+, and
lower limit of current: I-
One percent of the
rated current of the
instrument
Upper limit of power: P+, and
lower limit of power: P-
Rated power value of
the instrument
[On/Off] status Off
Config
menu
Mode CV
Copyright © Itech Electronic Co., Ltd.
119
