Basic Operation

Trig-In Indicates that the instrument

will trigger the running of one of

the functions below after receiv-

ing the external pulse signal.

Meter Triggers the run-

ning of Meter

function. This

function needs to

be triggered at

the upper com-

puter side

through SCPI in-

struction. For de-

tails, refer to

instructions re-

lated to ACQuire

in the Trigger

subsystem of the

Instruction

Manual.

Dlog Triggers the run-

ning of data re-

cording function.

List Triggers the run-

ning of List files.

Input Pin 4 receives the level signal from the

outside.

Output Pin 4 sends the digital signal (1, 0, PWM)

to the outside.

True By default (Not-Invert), the out-

put digital signal is 1 (i.e. low

level), and in the case of Invert,

the output is high level.

False By default (Not-Invert), the out-

put digital signal is 0 (i.e. high

level), and in the case of Invert,

the output is low level.

PWM Digital signal of PWM.

PWM Freq Frequency

136

ITech IT6012C-800-50 User Manual
