Quick Reference
The descriptions of configuration menu of the power supply are listed in the ta-
ble below.
Config Configuration menu of the power supply
Mode
CC/CV priority mode setting
CV
Constant voltage loop priority mode
Speed= High/Low
Loop response
speed setting:
high speed /
low speed
CC
Constant current loop priority mode
Speed= High/Low
Loop response
speed setting:
high speed /
low speed
V-Rise Time/I-Rise Time
= 0.001s
Displays the voltage or current rise time
setting according to the selected priority
mode. If CC priority mode is selected,
the parameter setting of I-Rise Time will
be displayed here.
V-Fall Time/I-Fall Time =
0.001s
Displays the voltage or current fall time
setting according to the selected priority
mode. If CC priority mode is selected,
the parameter setting of I-Fall Time will
be displayed here.
Output Res
Set the internal resistance of the power
supply. This parameter needs to be set
only when Mode is set to CV.
On Delay Set the delay time to turn on the output.
Off Delay Set the delay time to turn off the output.
Vmax
Set the upper limit of the voltage (de-
fault is the rated voltage of the instru-
ment). Once the voltage upper limit is
modified here, the parameters related
to the voltage setting will be limited by
the upper limit here.
