Power Supply Function
Charge /
Discharge
Set the test mode:
• Charge: Battery charging
• Discharge: Battery
discharging
According to the test require-
ments, choose one to set.
Charge /
Discharge
V
Set the voltage
value for charging
or discharging ac-
cording to the se-
lected test mode.
Charge /
Discharge I
Set the current val-
ue for charging or
discharging ac-
cording to the se-
lected test mode.
Charge /
Discharge
Time
Set the charging
or discharging
time according to
the selected test
mode.
Cut Off Voltage Battery test cut-off voltage
Cut Off Current
Battery test cut-off current
Cut Off Capacity Battery test cut-off capacity
This instrument supports battery discharge test in constant current and con-
stant power modes. If the user wants to discharge in constant current mode,
enter the Config menu, select the CC priority, set Vl to 0, set Vh to the rated
voltage value of the instrument, set P- to the rated power value of the instru-
ment, and then set the Battery menu according to the test requirements. If
the user wants to discharge in constant power mode, set P- to the specified
value, and set Discharge V and Discharge I to the rated voltage and current
value of the instrument.
1. Press the composite keys [Shift]+[I-set] (Function) on the front panel to en-
ter the function menu.
2. Use knob or Up/Down key to select 2.BATTERY: Off and press [Enter].
