ITech IT6512 User Manual

Function and Features
Copyright ©ITECH Electronic Co., Ltd. 15
CONFIG
CONFIG MENU
Configuration Menu
Load
Load Setup
Enables the dummy load.
Off
Automatically Return Meter function
disabled.
On
The function of Automatically return meter
after 5s enabled.
Ext-Ctrl Ext-Ctrl Setup
Ext-Ctrl mode and related parameter setting
10v-M
10V/5V monitoring mode options
5v-M
10V/10K-P
10V/10K or 5V/5K setting mode selection 5V/5K-P
V-P
Voltage(resistance)setting mode selection
R-P
Off
Disable this function
On
Limit
Voltage Range
Set the range of voltage.
Vmin= 1.000V Minimum voltage setting
Vmax= 80.000V
Maximum voltage setting
Online Online Setup
Online
connection mode
Parallel
Parallel/Series connection, press up/down key to
select.
Series
Master
Act as master/slave, press up/down key to select. Slave
Mount…
When as master, it will display “Mount…” (need
to set the count of slave) ; when as slave, it will
display “Addr…”(need to set the address of
instrument, range is 0 to 31)
Addr…
Off
Disable/Enable this function
On
OCP
OCP Setup
Set the status of OCP
Off
Disable over current protection function
On
Enable over current protection function
Func.
LIST
LIST MENU
List Menu
Off
Quit list mode
Recall
RECALL LIST
Recall the list file
Recall List File= 1
Select the list file
number
EditList
Edit list operation
EditSeq
Edit sequence operation
DIN40839
DIN40839
Evaluation of automobile starting waveform
12V
Select the 12V or 24V system
24V
Off
Enable/Disable DIN40839 function
