SCPI Status Register
Copyright © Itech Electronic Co., Ltd. 14
customer through BIT4 bit. The data bits in Status byte group will not be
latched, when the information in event register is changed, the correspo0nding
bit in status byte register will subsequently be changed.
Bit
Decimal
Value
Definition
0-2
Not used
0
Always set to 0.
3
QUES
8
One or more bits are set in the questionable
status
register (bits must be enabled in the enable
register).
4
MAV
16
Data is available in the power supply output
buffer.
5
ESB
32
One or more bits are set in the standard
event register (bits must be enabled in the
enable register).
6
RQS
64
The power supply is requesting service
(serial poll).
7
Not used
0
Always set to 0.
