ITech IT6922A - List Mode Operation and Editing

Function and Features
Copyright ©ITECH Electronics Co., Ltd. 21
List Mode (>List Set)
Before you edit a list file, please set the trigger mode: manual mode.
Press +
I-setI-set
button to enter the menu, then press direction key to
select >SYST SET option, after that please push
Enter
button to confirm. At
last please press direction key to select >Trig MANUAL and push
Enter
button to confirm.
You can make the output change order by editing every step value of list
operation. The parameters you need to edit includes: single-step voltage,
single-step current, single-step delay time and whether to go on the next step.
Besides, you also need to set the repeat times and save list sequence file. After
you finish the editing process, at this time if you receive a trigger signal, power
supply will begin to work according to the sequence steps you’ve edited. Now
we take five steps for an example:
Operation steps:
1. Press +
I-setI-set
（Menu）button to enter the menu
2. VFD display >MAX VOLT，press to select >LIST SET，press
Enter
to
confirm
3. VFD display >LIST STATE，press to select >LIST EDIT， press
Enter
to confirm
4. VFD display >TIME SEC，press
Enter
to confirm，go to the next step,
you can also through button to select >TIME MIN time unit，press
Enter
to confirm.
5. VFD display >VSET 0.000，press number key
0
to
9
or through
rotary knob to set voltage，after that press
Enter
to confirm.
6. VFD display ISET 0.0000, press number key
0
to
9
or rotary knob to
set the single-step current, press
Enter
to confirm.
7. VFD display SET 0.1，press number key
0
to
9
or rotary knob to set
single-step delay time，press
Enter
to confirm.
