Chapter2 Quick Start
This chapter introduces the front panel, the rear panel, key functions and VFD
display function of the power supply, make sure that you can quickly know the
appearance, instruction and the key function before you operate the power
supply. Help you make better use of this series of power supply.
2.1 Brief Introduction
IT6900 series power supplies are high performance single-output
programmable DC power supplied with communication interface. This series of
programmable DC power supply can output the maximum voltage or current
with a fixed power for customers. Take IT6922A (60V/5A/100W) for example,
when you select 60V for the output voltage, the output power of IT6922A is
100W, so in this case the maximum output current is 100W/60V = 1.66A. When
you select 20V for the output voltage, the maximum output current 100W/20V =
5A, but when the output voltage is down to 10V, due to IT6922A maximum
current is 5A, so in this case the maximum output current is 5A. IT6900 series
power comes with a standard communication interface RS232/USB/RS485,
both desktop and system-based features, can be designed and tested
according to your needs and provide multi-purpose solutions.
Convenient bench-top features:
High visibility vacuum fluorescent display (VFD)
Digital keyboard operation
High accuracy and high resolution
Low ripple and low noise
Intelligent fan control, energy conservation, noise reduction
Standard communication interface RS232/USB/RS485
Can be monitored by computer software
Output voltage and current values accordance with procedure
Can use the knob to adjust the voltage and current
Can adjust the numbers steps using the cursor
Rich SCPI orders to facilitate the formation of intelligent test platform
Can set the output timer (0.1 ~ 99999.9s)
External Analog Control Interface
