Function and Features
Copyright ©ITECH Electronic Co., Ltd. 14
Chapter3 Function and Features
3.1 Local/Remote Mode
Local button can enable you switch mode from remote to local mode.
After you power on the power supply, unit will default in local mode, all the
buttons can be used in this mode. While in remote mode, you can’t operate
through front panel directly. Local and remote mode can be controlled through
PC. In addition, the mode changing will not influence the output parameters.
3.2 Voltage Setup
You can set voltage within the range of rated voltage value. When you press
V
-
set
V
-
set
button, the button will be lit. This indicates that you can set voltage.
There are three ways to set output voltage through front panel.
 The first way: press
V-setV-set
,adjust cursor location through
button, pressing and will enable you to adjust the
setting voltage value.
 The second way: press
V
-set
V
-set
, adjust cursor location through
button, adjust rotary knob to change the setting voltage
value.
 The third way: press
V-setV-set
button and number key(
0
to
9
) to set
voltage value.
3.3 Current Setup
You can set current within the range of rated current value. When you press
I-setI-set
button, the button will be lit. This indicates that you can set current.
There are three ways to set output current through front panel.
 The first way: press
I-setI-set
,adjust cursor location through
button, push and will enable you to adjust the setting
current value.
