ITech IT7800 Series User Manual

Technical Specifications
Copyright ©ITECH Electronic Co., Ltd. 101
DC Output
Range
multichannel/reverse
-30 ～ 30
Adc
1phase
-90 ～ 90
Adc
Resolution
0.01
A
Accuracy
＜ 0.3%+0.3% F.S
Temperature
coefficient
< 200ppm/ ℃ F.S
Max. power
Phase power
Per Phase
3k
W
Max. power (reverse
phase)
Max. Power
（ reverse phase )
6k
W
Total power
Max. Power
（ 1phase/multichannel ）
9k
W
Programmable
impedance
Range
0Ω+200µH ～
1Ω+1mH
Voltage stability
Line regulation
＜ 0.05% F.S.
Load regulation
DC,16Hz ～ 500Hz
＜ 0.05% + 0.05% F.S.
500.01Hz ～ 2.4kHz
＜ 0.05% +
(0.1%*kHz) F.S
THD
16Hz ～ 100Hz
＜ 0.5%
100.01Hz ～ 500Hz
＜ 1%
500.01Hz ～ 2.4kHz
<1%+(1%*kHz)
Voltage ripple
RMS
< 0.4
V
Dynamic response*4
typ
200
us
Voltage Slew Rate,
Typical
≥2 V/µs with full-scale programmed voltage step
Output Isolation
550Vac
Measurement parameter
Voltage RMS
Resolution
0.01
V
Accuracy
DC,16Hz ～ 500Hz
＜ 0.1%+0.1% F.S.
500.01Hz ～ 2.4kHz
＜ 0.1%+(0.2%*kHz)
F.S
emperature coefficient
< 100ppm/ ℃ F.S.
Current RMS
Resolution
0.01
A
Accuracy
DC,16Hz ～ 150Hz
＜ 0.1% + 0.2% F.S.
150.01Hz ～ 500Hz
＜ 0.2% + 0.3% F.S.
500.01Hz ～ 2.4kHz
＜ 0.3% + (0.6%*kHz)
F.S
Temperature
coefficient
< 200ppm/ ℃ F.S.
Peak current
Resolution
0.01
A
Accuracy
DC,16Hz ～ 500Hz
＜ 0.4% + 0.6% F.S.
500.01Hz ～ 2.4kHz
＜ 0.4% + (1.2%*kHz)
F.S
Output power
Resolution
0.001
kW
Accuracy
DC,16Hz ～ 500Hz
＜ 0.4% +0.4% F.S.
500.01Hz ～ 2.4kHz
＜ 0.4% + ＜
(0.8%*kHz) F.S
Harmonic
measurement
Max.
50/60Hz
up to
50
orders
Others
Efficiency
typ
88%
Protection
OVP, OCP, OPP, OTP, FAN,ECP,Sense
Working
0 ℃ -50 ℃
Programming
response time
2ms
Remote
Sense
Compensation
Voltage
20V
Communication
interface
Built-in USB/CAN/LAN/Digital IO interface, optional GPIB / Analog&RS232
*2According to the output frequency, the output voltage will be reduced, the rated voltage can be out within 1.4K, the
maximum output voltage at 2KHz is 250.76Vrms and 2.4KHz is 208.97Vrms.
*3 When loopSpeed Low is low ， it can better complied DUT’s characteristics ； When LoopSpeed is High ， the dynamic
response time is faster.
*4 The dynamic response time test condition is: DC high-speed mode, and the capacitance of the DUT to be less than
10uF
All the above parameters are subject to change without prior notice from ITECH.
