Inspection and Installation
Copyright ©ITECH Electronic Co., Ltd. 34
⚫ Before connecting the cables, ensure that the instrument power switch is off
and the main switch of the AC power input (distribution box) is off.
⚫ Fiber optic cables cannot be flexed or folded. When the cable is too long
and needs to be arranged, gently wrap the cable in a circle and gently tie it.
As shown in the following figure, connect the System Bus between the master
and slave by fiber cords.
