ITech IT7915P-350-90

System-Related Functions
Copyright ©ITECH Electronic Co., Ltd. 106
Function
⚫ PS Clear
⚫ Input
⚫ Output
Digital IO-3: PS
Function setting of pin 3
Reverse
On/Off, Select Invert or not under the
IO Settings. If setting to ON, it means
the valid signal is reversed.
Function
⚫ PS
⚫ Input
⚫ Output
Digital IO-4: SYNC
Function setting of pin 4
Reverse
On/Off, Select Invert or not under the
IO Settings. If setting to ON, it means
the valid signal is reversed.
Function
⚫ Sync-in
⚫ Sync-out
⚫ Input
⚫ Output
Digital IO-5:
ON/OFF Status
Function setting of pin 5
Reverse
On/Off, Select Invert or not under the
IO Settings. If setting to ON, it means
the valid signal is reversed.
Function
⚫ ON/OFF Status
⚫ Input
⚫ Output
Digital IO-6: TRIG1
Function setting of pin 6
Reverse
On/Off, Select Invert or not under the
IO Settings. If setting to ON, it means
the valid signal is reversed.
Function
⚫ Trigger1-out
⚫ Trigger1-in
⚫ Input
⚫ Output
AC
On/Off: When On is selected, a trigger
signal is output when AC amplitude
changes. The accuracy of voltage change
is 100mV and is not restricted by phase.
(This configuration is displayed only
when the IO pin is set to Trigger1-out)
DC
On/Off: When On is selected, a trigger
signal is output when the DC amplitude
changes, and the voltage change
precision is 100mV.
(This configuration is displayed only
when the IO pin is set to Trigger1-out)
Freq
On/Off: When On is selected, a trigger
signal is output when the frequency
changes.The accuracy of frequency
change is 0.1Hz
(This configuration is displayed only
when the IO pin is set to Trigger1-out)
List
On/Off: When On is selected, the List
generates a trigger signal and outputs a
