ITech IT8500plus Series User Manual

Specifications
Copyright © Itech Electronic Co., Ltd. 61
Minimum
operation
value
0.2V at 12A
2V at 120A
CV mode
Range
0.1~18V
0.1~120V
Resolution
1mV
10mV
Accuracy
±(0.05%+0.02%FS)
±(0.05%+0.025%FS)
CC mode
Range
0~12A
0~120A
Resolution
1mA
10mA
Accuracy
±(0.05%+0.05%FS)
±(0.05%+0.1%FS)
CR mode
*1
Range
0.05Ω~10Ω
10Ω~7.5KΩ
Resolution
16bit
Accuracy
0.01%+0.08S *2
0.01%+0.0008S
CP mode
*3
Range
600W
Resolution
10mW
Accuracy
±(0.2%+0.2%FS)
Dynamic mode
Dynamic
mode
CC mode
T1&T2
100uS~3600S /Res:1 uS
Accuracy
10uS±100ppm
Rising/Falling
slope *4
0.001~0.2A/uS
0.01~1.6A/uS
Minimum rise
time *5
≒60uS
≒60uS
Measuring range
Readback
voltage
Range
0~18V
0~120V
Resolution
0.1 mV
1mV
Accuracy
±(0.025%+0.025%FS)
±(0.025%+0.025%FS)
Readback
current
Range
0~12A
0~120A
Resolution
1mA
10mA
Accuracy
±(0.05%+0.05%FS)
±(0.05%+0.1%FS)
Readback
power
Range
600W
Resolution
10mW
Accuracy
±(0.2%+0.2%FS)
Protection range
OPP
Protection
≒620W
OCP
Protection
≒13A
≒130A
OVP
Protection
≒125V
OTP
Protection
≒95℃
Specification
Short
Current( CC )
≒13/12A
≒130/120A
Voltage( CV )
0V
0V
Resistance( CR
)
≒15mΩ
≒15mΩ
Input
Impendance
150KΩ
Weight
7.1KG
Dimension
214.5mm*88.2mm*453.5mm
*1 The voltage/current input is no less than 10% FS
*2 The scope of read-back resistance is: (1/(1/R+(1/R)*0.01%+0.08),1/(1/R-(1/R)*0.01%-0.08))
*3 The voltage/current input is no less than 10% FS
*4 Ascending/descending slope: 10%-90% current ascending slope from 0 to maximum current.
