Fig 7 - silencer assembly (detail)
Fig 9 - Safety shutoff valve assembly (detail)
4 Screws
DN25-40-50: M1
0
DN80: M14
DN100: M1
2
The setting key - ref. 20231000 - is
provided on request. It may be kept into
the regulator diaphragm housing.
Adjustment
screw
Setting k
ey
Fig 8 - Setting key
3400992804 20.07.2009 13:19 Uhr Seite 12
Fig 8 - Setting key / Justierschlüssel
Fig 7 – silencer assembly (detail) /
Schalldämpfer
Fig 9 – Safety shutoff valve assembly (detail) /
SAV Baugruppe
4 Screws / 4 Schrauben
DN25-40-50: M10
DN80: M14
DN100: M12
Der Justierschlüssel – Nr� 20231000 –
kann bei Bedarf geliefert werden�
The setting key – ref� 20231000 -
is provided on request�


Setting key / Justierschlüssel
Adjustment
screw /
Justier-
schraube
