Sectional view
Fig 1 - RB 4000 sectional view
Breather
Loading
spring
Actuator
Anti-pumping
valve
Adjustment screw
Diaphragm
Valve disc
Valve seat
Sensing line
SSV
Sensing line
Safety Shutoff valve (SSV
Fig 2 - RB 4000 with built-in safety shutoff valve
