6
Outlet Pressure Range DN 25
Spring Code
Spring Characteristic Spring Range
d
(mm)
Di
(mm)
Lo
(mm)
Lt Colour 4010/11/12
(ø 360)
4020/21/22
(ø 220)
4030/31/32
(ø 220/TR)
20567075 3�5 43 200 15�5 Yellow 18 - 27 mbar • •
20567076 3�5 43 200 10�75 Red 25 - 33 mbar • •
20567662 4�5 43 160 11 White 25 - 55 mbar • •
20567663 5�5 43 160 10�5 Lilac 55 - 100 mbar 0�12 - 0�20 bar •
20567664 6�5 43 160 10�5 Orange 85 - 210 mbar 0�20 - 0�55 bar •
20567665 7 43 140 10�5 Brown • 0�30 - 0�65 bar 0�50 - 1�00 bar
20567666 7�5 43 160 10�5 Green • 0�40 - 0�90 bar 0�60 - 1�35 bar
20567761 8 43 140 9 Black • • 1�10 - 1�70 bar
20567762 9 43 140 9 Grey • • 1�10 - 2�50 bar
RB DN 40 / DN 50 / DN 50 x 80
Spring
Code
Spring Characteristic Spring Range
d
(mm)
Di
(mm)
Lo
(mm)
Lt Colour 4010/11/12
(ø 480)
4020/21/22
(ø 360)
4030/31/32
(ø 360/TR)
20568085 4 63 320 15 Orange/Sliver 10 - 14 mbar • •
20568086 4 63 320 10�5 Brown/Silver 14 - 19 mbar • •
20568087 5 63 320 16�5 Dark Green/Silver 19 - 27 mbar • •
20568088 5 63 320 13 Light Green/Silver 25 - 36 mbar • •
20568089 5 63 320 9�25 Light Blue/Silver 35 - 48 mbar 0�068 - 0�107 bar •
20568081 6�5 63 270 9�75 Purple/Silver 50 - 85 mbar 0�11 - 0�18 bar •
20568082 8�5 63 270 15 Yellow 82 - 130 mbar 0�18 - 0�28 bar •
20568083 8�5 63 270 11�5 Blue/Silver 110 - 140 mbar 0�28 - 0�37 bar •
20568183 9 63 260 11�5 Blue 120 - 240 mbar 0�27 - 0�45 bar •
20568283 9 63 243 10�8 Blue • 0�30 - 0�50 •
20568282 10 63 243 11 Silver • 0�48 - 0�66 0�70 - 1�02
20568281 11 63 243 11 Purple • 0�65 - 0�82 0�99 - 1�20
20568286 11�5 63 243 10�8 Yellow/Silver • 0�80 - 1�00 1�18 - 1�55
20568284 12 63 243 10 Red/Silver • 0�99 - 1�30 1�50 - 2�00
DN 80 / DN 100
Spring
Code
Spring Characteristic Spring Range
d
(mm)
Di
(mm)
Lo
(mm)
Lt Colour 4010/11/12
(ø 600)
4020/21/22
(ø 480)
4030/31/32
(ø 360/TR)
4040/41/42
(ø 360/TR)
20569590 6 80 350 12�5 Orange 17 - 25 mbar • • •
20569591 6�2 80 350 10 Brown 23 - 30 mbar • • •
20569592 6�5 80 350 10 Dark Green 28 - 37 mbar • • •
20569593 7 80 350 9�5 Light Green 38 - 54 mbar • • •
20569594 8 80 350 11�5 Black 43 - 68 mbar • • •
20569690 9 80 320 10�5 Red 58 - 96 mbar • • •
20569691 9�5 80 320 10 light Blue 72 - 117 mbar • • •
20569585 11 80 320 10�5 White 94 - 170 mbar • • •
20569586 13 80 320 12�5 Pink 150 - 200 mbar • • •
20568082 8�5 63 270 15 Yellow • 0�082 - 0�13 bar • •
20568083 8�5 63 270 11�5 Blue/Silver • 0�11 - 0�14 bar • •
20568183 9 63 260 11�5 Blue • 0�12 - 0�24 bar • •
20568283 9 63 243 10�8 Blue • • 0�30 - 0�50 bar •
20568182 10 63 260 11�5 Silver • 0�18 - 0�29 bar • •
20568282 10 63 243 11 Silver • • 0�48 - 0�66 bar 0�70 - 1�02 bar
20568181 11 63 260 11�5 Purple • 0�24 - 0�37 bar • •
20568281 11 63 243 11 Purple • • 0�65 - 0�82 bar 0�99 - 1�20 bar
20568186 11�5 63 260 11�5 Yellow/Silver • 0�30 - 0�47 bar • •
20568286 11�5 63 243 10�8 Yellow/Silver • • 0�80 - 1�00 bar 1�18 - 1�55 bar
20568184 12 63 260 10�5 Red/Silver • 0�38 - 0�50 bar • •
20568284 12 63 243 10 Red/Silver • • 0�99 - 1�30 bar 1�50 - 2�00 bar
Spring characteristics:
d: wire diameter Lo: height
Di: internal diameter Lt: no� of spires
