8. DESCRIPTION AND INSTALLATION
8.1 Physical Description
The functional components of the ADRA1000/2000 are located on its bottom
panel. The LEDs are on the front panel. The back panel has two indented holes
for wall mounting.
8.1.1 Bottom Panel
9VDC
Line 1
Line 2
ADRA 2000 Only
Figure 8-1. ADRA 1000/2000 Bottom Panel
ADRA 1000/2000 Installation and Programming Manual 8-1
