ITS Telecom EAR 1000 - DTMF Programming Commands; Script Messages

DTMF Programming
9.2 DTMF Programming Commands
The following tables show the DTMF commands available for the
ADRA 1000/2000 system.
9.2.1 Script Messages
OPERATION COMMAND DEFAULT
To Record an Opening
Greeting.
In the ADRA 2000 it is
possible to define whether
to use different greetings
for lines 1 and 2 or to use
the same greetings for both
lines. Refer to command
*112 below.
Note: In case of re-
recording, it’s
recommended to first delete
the existing message.
*100 + XX + Beep + Record + #
where:
XX = 00; Day greeting
XX = 10; Night greeting
XX = 20; Holiday greeting
XX = 22; Busy greeting
XX = 21; No answer greeting
XX = 01; Transfer greeting
The following are only available for
the second line of ADRA 2000
XX = 50; Day greeting
XX = 60; Night greeting
XX = 70; Holiday greeting
No message is
recorded.
9-2 ADRA 1000/2000 Installation and Programming Manual
