After START, Turntable is running continously, film
carriage does not rise at all,even there is high pallet
on turntable
1. Table home proximity can be disconnect, damaged or have a bad alignment Check the proximity alignment and connections
2. Carriage up limit switch can be activated, disconnected or damaged Check the switch and connections
TROUBLESHOOTING
4 mm
-X4
17
Other problems
