ITW Mima Ecomat EASY - Machine Stops After Layers, Carriage Not Rising

After START, Machines makes selected numbers of
layers (bottom+top) + 2 additional, and stops. Film
carriage does not rise at all
even there is high pallet
on the turntable
1. Carriage lifting motor can be disconnected Check the cable and connectios
2. Carriage up limit switch can be disconnected or damaged Check the switch and connections
18
TROUBLESHOOTING
Other problems
