IVT 12PHR-N User Manual

GB-2
PART NAMES
1 Inlet (Air)
2 Filter cover
3 Air Filter
4 Air Purifying Filter
5 Receiver Window
6 AUX Button
7 Release Button
8   
9 Outlet (Air)
10 Open Panel
11
Receiver Window
12 TEMPERATURE Indicator
13 OUTDOOR Temp. Lamp (green
)
14 FULL POWER Lamp (green
)
15 TIMER Lamp (orange
)
16 OPERATION Lamp (red
)
17 PLASMACLUSTER Lamp
(blue
)
18 Inlet (Air)
19 Refrigerant pipe and
Interconnecting Cord
20 Drainage Hose
21 Outlet (Air)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
OUTDOOR UNIT
NOTE:
Actual units might vary slightly
from those shown above.
INDOOR UNIT

IVT 12PHR-N Specifications

General

Brand	IVT
Model	12PHR-N
Category	Air Conditioner
Language	English
