Commissioning
AirModule 6 720 813 268(2014/10)
38
10.4 Service menu overview
11 Commissioning
11.1 General user interface commissioning
Menu Purpose of the menu Page
Startup Start the configuration wizard and configure the system by checking/modifying the most important settings. 38
Heat pump Configure the heat pump by checking/modifying the most important settings. 42
Set booster heater Configure the booster by checking/modifying the most important settings. 43
Set heating/cooling System data Settings that apply to the entire system, e.g. min. outside temperature and type of building. In this menu you
can further select settings for heating/cooling circuit 1 and the DHW system (if it is directly connected to the
heat pump module).
44
Heating circuit 1 ...
4
Specific settings for installed heating/ cooling circuits 1 to 4, e.g. frost protection and heating curve. 46
Screed drying Configurable program for screed drying of a new floor plate with an underfloor heating system. 50
DHW settings DHW system settings, e.g. max. hot water temperature, time of thermal disinfection and configuration of the
hot water DHW circulation pump.
52
Pool settings Configure the pool heating by checking/modifying the most important settings. 53
Solar settings If solar heating is installed: please refer to the solar module technical information. 53
Hybrid system Set energy price relationship. 53
Anti-seizing protection Determine a start time for short term activation of pumps and valves, to prevent these components from
seizing (motion operation).
53
Diagnosis System diagnostics:
• Perform function test of separate actuators (e.g. pumps).
• Compare set values and actual values.
• Show current operating errors and error history.
• Display EMS BUS unit software version.
Other functions:
• Enter contact address.
• Reset different settings.
• Calibrate the clock.
54
Table 19 Service menu overview
The compressor in the heat pump warms up before it
starts. This can take up to 2 hours, depending on the
outside temperature. The requirement is that the
compressor temperature is 10 K above the air intake
temperature. The temperatures are visible in the
Diagnostics menu ( Chapter 12.9).
&
Setting the language
▶ Turn the selector to select a language and press the selector
to confirm.
Setting the date
▶ Turn the selector and press it to set day, month, and year.
The word Continue is highlighted.
▶ When the date is correctly set, press the selector to save the
date.
Setting the time
▶ Turn the selector and press it to set hours and minutes.
The word Continue is highlighted.
▶ When the time is correctly set, press the selector to save the
time.
Setting the country
▶ Turn the selector and press it to set in which country the heat
pump has been installed.
Setting buffer cylinder installation
▶ Turn the selector and press it to set if a buffer cylinder/
storage cylinder has been installed.
System configuration
▶ Turn and press the selector to start the (Yes) or skip the (No)
configuration wizard.
▶ If the configuration wizard starts, the user interface will
automatically detect the BUS units installed in the system
(system analysis) and adjust the menu and standard settings
accordingly.
▶ System commissioning ( Chapter 11.2).
Table 20 Commissioning general settings
