IVT GreenlineC - Page 43

44
Example 200 metres of hose type 40/35 with Brinol gives 200 x 0.29 litres Brinol/ meter = 58 liter
Brinol and 200 x 0.71 litres water/ metres = 142 litres water.
Safety valve
Expansion vessel
Filling and venting valve
*Manual venting valve
*If the expansion vessel
cannot be placed in the
highest position then manual
venting is recommended.
Particle
filter
IVT Greenline
3
1
The table shows the mixture in volume litre/ metre
Hose
type
Antifreeze
type
Ethanol
Propylene
Litres of water
0.71
0.65
Litres of antifreeze
40/35
0.29
0.35
0.42
0.39
Litres of antifreeze
0.18
0.21
32/28
The table shows the mixture in weight percent
Ethanol
Propylene
25%
35%
Hose type
40/35
32/28
Litres of water
