IVT GreenlineC - PAGES FOR THE INSTALLER

31
Dimensions and connections, C series
Dimensions are given in mm
(1) Return radiator
(2) Riser radiator
(3) Cold water in
(4) Hot water out
(5) Heat transfer fluid in
(6) Heat transfer fluid out
Electrical
connections
Front
®®®
®
(1)
(2)
(3)
(4)
(6)
(5)
600
®®
®® ® ®
®
®
®
85 240 360 460 525
85
65
500
600
345
225
40
1770
