4.1.15 Electric Actuator Fitted to Chlorine Institute Yoke & Siemens Vacuum Regulator
Standard Fitting with No
Vacuum Regulators
Chlorine Institute Yoke with
vacuum regulators
(Siemens equipment)
For 70kg cylinders there is no
requirement for additional adaptors
If a Chlorine Institute yoke is used to
fit the vacuum regulators (Siemens
equipment) the support bracket simply
fits between the valve body and yoke.
For 920kg drums using vacuum
regulators with heater tubes (Siemens
equipment) a small 80mm extension
that is attached to the heater tube will
be required to provide adequate
clearance for the actuator from the
regulator body.
