4.1.18 Pneumatic Actuator Fitted to Chlorine Institute Yoke and Siemens Vacuum Regulator
Standard Fitting with No
Vacuum Regulators
Chlorine Institute Yoke with
vacuum regulators
(Siemens equipment)
For 70kg cylinders there is no
requirement for additional adaptors
If a Chlorine Institute yoke is used to
fit the vacuum regulators (Siemens
equipment) the support bracket
simply fits between the valve body
and yoke.
For 920kg drums using vacuum
regulators with heater tubes
(Siemens equipment) a small 80mm
extension that is attached to the
heater tube will be required to
provide adequate clearance for the
actuator from the regulator body.
