4.1.20 PLC Touch Screen Operation Menus
The following information can be obtained via the Touch Screen.
Chlorguard Main Screen
Figure 1.
Control Description
System –
Function 1 – Alarm Configuration
Function 2 – SMS Configuration
Function 3 – Leak Detection Simulation Test
Function 4 – Service Menu
Main UI Screen
Displays the actuators attached to the Chlorguard
unit and their current status
