Approved Installation Manual for the Experimental Report No 104
EDM-350 Page 43 of 46 Rev A
Engine Data Management System Date 7-10-2021
44. J3 RPM, MP, Oil-P
J3
Green 6
Green 8
9 NC
green 1
black 2
red 3
black 7
red 4
black 5
1
2
3
RPM sig
RPM ground
RPM power
RPM
420815-1 or,-2
MAP i2S (0-5v) PN
159934A
0-30 psia
Oil-P (i2s 0-5v) PN
159936A
0-150 psi
power
ground
signal
ground
signal
Oil-P
OIL-P
MAP
J-3 Harness with i2s Oil and manifold pressure sender
