J.P. Instruments EDM-350 User Manual

Approved Installation Manual for the Experimental Report No 104
EDM-350 Page 29 of 46 Rev A
Engine Data Management System Date 7-10-2021
26. Component Parts
Single engine
-4 Cyl
-6 Cyl
Display EDM-350 P/N 350000-(xxx)
1
1
EGT probe KIT PN 1280
4
6
TIT probe with option KIT 1200
1
1
CHT probe KIT PN 1260
4
6
OAT probe with option KIT 1300
1
1
IAT probe with option KIT 1144
1
1
Carb temp probe KIT 1250 PN 500409
1
1
Oil Temp probe with option KIT 1255 PN 400509
1
1
Oil pressure sender KIT 1460 PN 159936A
1
1
Fuel pressure sender KIT 1450 PN 159935A
1
1
Fuel pressure differential sender Kit 1480 PN 159938
1
1
Ammeter shunt PN 159920
1
1
Fuel Flow transducer PN 700900-1 or -2
1
1
Fuel Level sender option
1
1
MAP KIT 1440 PN 159934A
1
1
RPM one of P/N 420806 or 420809 Pressurized
1
1
RPM one of P/N 420815-1, -2 Non Pressurized
1
1
RAD P/N-790749
1
1
26.1 Component Parts List for EGT (KIT 1280), TIT (KIT 1200) Probe
1 Thermocouple type K probe PN M-111
1 Stainless Steel Clamp Thimble
1 Stainless Steel Exhaust Seal Washer
1 Stainless Steel Screw Type Clamp
2 Ring Terminals
2 Screws and nuts 6-32 X 1/4
1 Fiberglass tube 3/8” x 5”
26.2 Component Parts list for CHT KIT 1260
1 Bayonet Probe Thermocouple type K Spring loaded PN 5050
2 Ring Terminals
2 Screws and Nuts 6-32 X 1/4"
1 Fiberglass tube 3/8” x 5”
26.3 Component Parts list for IAT (KIT 1300) probe
1 Thermocouple type K probe PN M-111
1 Stainless Steel Clamp &Thimble
1 Stainless Steel Exhaust Seal Washer
26.4 Component Parts list for OAT (KIT 1220) probe
1 P/N 400510, OAT probe
2 Ring Terminals
2 Screws and Nuts 6-32 X1/4"
Fiberglass tube 3/8” x 5”
26.5 Component Parts list for CARB (KIT 1190) probe
1 P/N 400128, CARB probe
2 Ring Terminals
2 Screws and Nuts 6-32 X1/4"
1 Fiberglass tube 3/8” x 5”
