12 LIST OF COMPONENTS IN ILLUSTRATIONS
Figure
Item
Description
1
1
Top cover magnet
2
Top cover
3
Cover
4
Blades
5
Front table
6
Oil counter reset button
7
Crumb tray
8
Front door
9
Bagger
10
Emergency stop button
11
Green indicator lamp or illuminated button
12
Counter
13
Braked castor
2
14
Rear panel
15
Power cable
3
16
Rear table
17
Magnetic lock
18
Work area
7
19
Bagger-blower
20
Blower control button
8
21
Safety cell
9
22
Safety bar
10
23
Mechanical safety switch
11
24
Mechanical safety switch
13
25
“Cut hazard” sign
26
Circuit diagram
27
“Electrocution hazard” sign
14
28
Detachable loaf holder spring
15
29
Bagger adjustable stop
