- 27 -
1、纽钳机构部件/
Button clamp mechanism components
序号
零件件号
名称
数量
DESCRIPTION
1
300145
钮钳座
1
BUTTON CLAMP HOULDER
2
40902001
钮针提升杆
1
BUTTON CLAMP LIFTING HOOK
3
402S14006
螺钉
2
SCREW 15/64-28 L=9
4
409S12001
螺钉
2
SCREW 3/16-32 L=13.5
5
40928001
垫圈
2
WASHER 5×10.5×1
6
413S14004
螺钉
2
SCREW M3
7
4091200100
纽钳杆座组件
1
BUTTON CLAMP
7-1
40912002
钮夹控制座
1
JAW LEVER HOLDER
7-2
409S20002
轴位螺钉
1
HINGE SCREW D=5.5 H=1.8
7-3
40912003
钮夹止动杆
1
SNAP FASTENER CLAMP STOP LEVER
7-4
409S20001
合叶螺钉
1
HINGE SCREW D=5.5 H=3
7-5
409S20003
钮夹螺钉
1
CLAMP SCREW
7-6
40927001
钮夹弹簧
1
BUTTON CLAMP SPRING
7-7
40912008
右钮夹钳夹
1
BUTTON CLAMP LEVER JAW RIGHT
7-8
409S20005
轴位螺钉
2
HINGE SCREW D=6.35 H=3.9
7-9
409S20004
钮夹止动销
2
BUTTON CLAMP STOP PIN
7-10
40901003
钮夹滑块
1
BUTTON CLAMP SLIDE
7-11
409S16001
螺母
1
NUT
7-12
40912009
钮夹右弹簧压板
1
BUTTON HOLDING SPRING RIGHT
7-13
409S11002
螺钉
2
SCREW 9/64-40 L=3.5
7-14
40912006
钮扣左弹簧压板
1
BUTTON HOLDING SPRING LEFT
7-15
40912005
左钮夹钳夹
1
BUTTON CLAMP LEVER JAW LEFT
8
40902002
合叶销
1
HINGE PIN
9
409S30002
钮钳调压杆
1
BUTTON CLAMP PRESSUER ADJUSTIN
10
40927002
钮夹压力弹簧
1
PRESSUER ADJUSTING SPRING
11
409S16003
螺母
2
NUT M6
12
40927003
手指保护架
1
FINGER GUARD
13
30128010
垫圈
2
WASHER
14
402S11007
螺钉
2
SCREW 11/64-40 L=3.5
15
H05002
卡簧
2
SNAP PIN
16
409S30001
钮钳塞销
1
PICK-UP DEVICE STOPPER PIN
17
401S16002
螺母
1
NUT M6
