9.线调节杆的调整（ADJUSTMENT OF THE THREAD PULL -OFF LEVER）
To adjust the thread pull-off lever,insert a screwdriver through an opening
in the machine arm side cover (left),loosen screw and adjust the position
of nipper bar block (rear)to the left or the right . If the end of the
thread is drawn from arrow hole A in the button after sewing ,change the
position of nipper bar block (rear) to the left .Move the lever to the right
when the thread end comes out from arrow hole B .
10.针导向器的位置（POSITION OF THE NEEDLE GUIDE ）
调节线调节杆时时，请把螺
丝刀插进左侧面板上的孔中，拧松
固定螺丝，然后左右移动调节杆
的活动 滑块 进 行 调整。缝 制 结
束，如果线头从A部前头的孔中露
出时，请把线调节杆活动滑块向
左移动，如果线头从B部箭头的孔
中露出时，请把滑块向右移动，不
让线头露出来。
在针杆最下点，拧松螺丝，左右移动针
导向器，把机针和针导向器的间隙调
整为0.05～0.1mm
Loosen screw and provide a 0.05 to
0.1mm clearance between the needle
guide and the needle by moving
the needle guide to the left or
the right when the needle is in the
lowest position .
