- 31 -
3、下轴部件/
Looper shaft mechanism components
序号
零件件号
名称
数量
DESCRIPTION
1
40908002
挡圈
1
THRUST COLLAR D=7.94 W=7
2
409S11012
螺钉
1
SCREW 9/64-40 L=6.1
3
409S11031
螺钉
1
SCREW
4
409S11010
螺钉
1
SCREW
5
40912021
导向线杆（打捆针导向器）
1
NEEDLE GUARD
6
40909001
插入导向滑板
1
POSITONGNING FINGER YOKE SLIDE
7
409S17001
螺钉
2
SCREW M4 L=9
8
40909002
导向卡箍（压铁插孔）
1
YOKE SLIDE INSERT
9
40912022
滑块（轭铁片）
1
YOKE SLIDE
10
4090500100
环形定位杆
1
ASSY LOOP POSITIONING FINGER L
11
40903003
滚珠
1
LOOP POSITIONNING FINGER CAM RO
12
409S20008
轴位螺钉
1
HINGE SCREW D=6.35 H=2.4
13
－－－－－
针板组件
1
THROAT PLATE SET
13-1
40901005
针板
1
THROAT PLATE ASM.
13-2
40919003
定刀
1
COUNTER KNIFE
13-3
－－－－－
螺钉
2
SCREW1/8-44 L=3.0
13-4
4091900100
动刀
1
MOVING KNIFE ASM.
13-5
－－－－－
螺钉
1
HINGE SCREW D=6 H=0.85
14
409S11009
螺钉
3
SCREW M4 L=9
15
40910001
环形凸轮
1
LOOP POSITIONING FINGER CAM
16
409S14002
螺钉
4
SCREW 11/64-40 L=3.5
17
40902006
连接轴
1
CAM AND LOOPER SLEEVE
18
409S15004
螺钉
2
SCREW 15/64-28 L=4.0
19
40910002
后凸轮
1
LOOP POSITIONGNING FINGER CAM RE
20
40903046
下轴前套
1
LOOPER SHAFT BUSHING FRONT
21
401S14001
螺钉
2
SCREW
22
40908001
挡圈
1
THRUST COLLAR ASM, D=11.11,W=10
23
402S14002
螺钉
2
SCREW 1/4-40 L=5
24
－－－－－
下轴齿轮组件
1
THRUST COLLAR ASM, D=11.11,W=1
24-1
40925002
勾线轴齿轮
1
LOOPER SHAFT DRIVER GEAR ASM.
24-2
－－－－－
螺钉
4
SCREW 1/4-40 L=6
25
40924001
端面轴承
1
THRUST BALL BEARING
26
40928004
轴承垫圈
1
BEARING WASHER
27
40903005
下轴后套
1
LOOPER SHAFT BUSHING REAR
28
－－－－－
蜗杆组件
1
WORM ASM.
28-1
40925011
蜗杆
1
WORM
28-2
－－－－－
螺钉
2
SCREW 1/4-40 L=7
29
－－－－－
凸轮轴从动齿轮组件
1
CAM SHAFT ASM.
29-1
40925001
凸轮轴从动齿轮
1
CAM SHAFT DRIVEN GEAR.
30
40902026
下轴
1
LOOPER SHAFT
31
40917001
钩圈
1
LOOPER
