Jack JK-T1377E - Page 33

- 33 -
4、绕线和过线部件
/
Nipper & tension parts components
序号
零件件号
名称
数量
DESCRIPTION
1
409S11013
螺钉
1
SCREW M6 L=12
2
————
针杆防护罩(附件)
1
NEEDLE BAR GUARD
3
40913012
2号导线钩
1
THREAD GUIDE
4
4091202500
导线装置
1
NIPPER COMPL
4-1
————
轴位螺钉
1
SHOULDER SCREW
4-2
409S16005
螺母
2
NUT
4-3
409S16006
松线螺母
1
NUT
4-4
409S20011
松线销
1
LOOPER SHAFT BUSHING REAR
4-5
40927007
夹线杆拉伸弹簧
1
NIPPER BAR BLOCK SPRING
4-6
409S30004
弹簧销
1
NIPPER BAR BLOCK SPRING SCREW
5
40909003
夹线座
1
NIPPER BLOCK ASM.
5-1
409S20012
螺钉
1
HINGE SCREW D=4 H=20
5-2
40927008
夹线座弹簧
1
HIPPER SLIDE BLOCK SPRING
5-3
————
夹线座
1
NIPPER BLOCK
6
4091300400
引线杆组件
1
THREAD PULL OFF LEVER ASM.
7
409S20014
驱动杆轴位螺钉
1
SHOULDER SCREW D=7.94 H=8
8
4091202700
夹线杆驱动杆组件
1
NIPPER BAR ACTUATING LEVER ASM.
9
40926006
导线杆
2
THREAD GUIDE PIN
10
409S20013
螺钉
1
SHOULDER SCREW D=7.94 H=15
11
409S11014
螺钉
1
SCREW
12
40912029
夹线杆驱动块
1
NIPPER BAR BLOCK
13
40912030
拨线杆驱动块
1
TENSION LEVER ROCKING PIECE
14
40912031
夹线杆
1
NIPPER BAR
15
409S11014
螺钉
1
SCREW
16
4091300600
2号夹线杆组件
1
TENSION POST ASM NO.2
16-1
409S16007
调节螺母
1
TENSION NUT
16-2
40912032
夹线器防松盘
1
ROTATION STOPPER
16-3
40927009
夹线器弹簧
1
THREAD TENSION SPRING
16-4
40912033
松线板
1
THREAD TENSION DISK PRESSER
16-5
40913007
夹线板
2
THREAD TENSION NO.1
16-6
409S30006
第二夹线杆
1
TENSION POST NO.2
16-7
409S16008
夹线板松线杆
1
TENSION RELEASE PIN
16-8
40926008
螺母
1
NUT M6
17
P03009
弹性圆柱销
1
SPRING PIN 3×16
18
409S11014
螺钉
1
SCREW
19
40928001
垫圈
1
WASHER
20
40912034
释压杆
1
THREAD TENSION RELEASING LEVER
21
4091300800
1号夹线器组件
1
ASSY HTREAD RENSION NO.1
21-1
409S16009
调节螺母
1
THREAD TENSION NUT
21-2
40927010
夹线器弹簧
1
FIRST THREAD TENSION SPRING
21-3
40913007
夹线板
2
THREAD RENSION DISK NO.1
21-4
409S30007
第一夹线杆
1
THREAD RENSION POST NO.2
22
40913009
导线钩
1
THREAD GUIDE
23
40913010
二眼线板
1
THREAD GUIDE NO.1
24
409S16024
螺母
1
NUT M4
25
409S11013
螺钉
1
SCREW M5 L=14
26
40912100
夹线杆滑块
1
NIPPER BAR BEARING BLOCK
27
409S30008
调节螺钉
1
ADJUSTING SCREW
28
409S11015
螺钉
1
SCREW M6 L=12
29
409S11016
螺钉
1
SCREW
30
40927011
2号钳杆弹簧
1
THREAD TENSION SPRING
31
409S30009
夹线杆拉伸弹簧销
1
NIPPER BAR SPRING SCREW
32
40928005
垫圈
1
WASHER 5×10.5×1
