Jack JK-T1377E - Page 39

- 39 -
7、推针滑轮轴部件/
Needle driving pulley shaft components
序号
零件件号
名称
数量
DESCRIPTION
1
40903045
滑轮轴左套
1
PULLEY SHAFT BUSHING LEFT
2
40603020
挡圈
2
THRUST COLLAR
3
413S14001
螺钉M6x6
4
SCREW M6
4
40925004
滑轮轴齿轮
1
DRIVING GEAR(A) ASM.
5
409S14001
螺钉
2
SCREW 1/4-40 L=6
6
40902051
驱动轴
1
NEEDLE DRIVING PULLEY SHAFT
7
40903044
驱动轴右套
1
PULLEY SHAFT BUSHING RIGHT
8
401S14001
螺钉
2
SCREW
9
930000047
手轮
1
PULLEY
10
413S14001
螺钉M6
2
SCREW M6
11
40910021
平衡凸轮
1
BALANCE CAM
12
402S14002
螺钉
2
SCREW
13
40910007
偏心轮
1
ECCENTRIC CAM
14
14-1
14-2
14-3
14-4
14-5
14-6
40933004
40933010
40933011
40933012
40933013
40911020
409S17003
电机组件
定子
转子
光栅片
电机编码器
电机罩壳
长螺钉
1
1
1
1
1
1
4
Motor
Stator components
Rotor components
Gratings components
Encoder
Motor cover components
Screw M5×55
