Jackson MSC TEMPSTAR - Dimensions Tempstar SDS

DIMENSIONS TEMPSTAR SDS
8
A - Drain 1 1/2” I.P.S.
B - Water inlet 3/4” I.P.S.
C - Electrical connection
D - Standard wall clearance with dishtable 4”
2 7/8”
2 1/2”
2 1/2”
15 1/2”
25 1/4”
25 1/4”
32”
17 1/2”
OPEN
76”
7 1/4”
14”
60 3/4”
74”
34”
TABLE
HEIGHT
A
C
B
A
B
D
D
LEGEND
