ITEM QTY DESCRIPTION Mfg. No.
1 1 Gauge, Pressure, 0-100 PSI 6685-111-88-34
2 1 Valve, Ball, 1/4" NPT 4810-011-72-67
3 1 Tee, 1/4" x 1/4" x 1/4" Brass 4730-011-51-20
4 2 Nipple, 1/4" Close Brass 4730-207-02-00
5 1 Regulator, Pressure 6685-111-48-54
6 1 Gauge, Pressure, 0-100 PSI 1/8" 6685-011-48-32
7 1 Reducer, 1/4" Male x 3/8" Female Brass 4730-011-59-40
8 1 Fitting, 3/8" Y-Branch 4730-111-58-21
9 1 Valve, Solenoid, 3/4" NPT 4810-100-03-18
10 2 Nipple, Close, 3/4" NPT 4730-207-34-00
11 1 Tee, Brass, 3/4" NPT x 3/4" NPT x 1/4" NPT 4730-211-04-00
12 1 Water Pressure Regulator, 3/4" NPT 6685-011-58-22
1
2
3
4
6
5
7
8
9
10
11
10 12
Please refer to the Incoming Plumbing Assembly, compo-
nent numbers 7 through 14 for the components to connect
to the Booster Tank.
