Jackson MSC TEMPSTAR - Dimensions Tempstar;Tempstar NB(Top Mounted Control Box)

DIMENSIONS TEMPSTAR/TEMPSTAR NB (TOP MOUNTED CONTROL BOX)
7
25 1/4”
32”
17”
MACHINE
OPENING
64 3/8”
34”
TABLE
HEIGHT
76”
W/ DOOR
OPEN
14 3/8”
DRAIN
TO
FLOOR
61 3/4”
60 5/8”
A- WATER INLET (3/4” IPS)
B- ELECTRICAL CONNECTION POINT
C- DRAIN (1 1/2”IPS)
D-STANDARD CLEARANCE BETWEEN
MACHINE AND WALL (WITH DISHTABLE) IS 4”.
15 1/2”
4 7/8”
A
B
D
D
B
C
LEGEND
