Jackson MSC TEMPSTAR - Incoming Plumbing;Outlet Plumbing Assembly

INCOMING PLUMBING/OUTLET PLUMBING ASSEMBLY
27
When servicing plumbing components, take care not to damage the threads of each individual item. Damaged threads can cause leaks
and loss of pressure, which could adversely effect the performance of the Tempstar dishmachine. It is strongly recommended that teflon
thread tape, used in conservative amounts, be applied to threads when joining components together. It is not advised to use thread
sealing compounds, sometimes referred to as “pipe dope”. Compounds can be ejected from the threads during the tightening process
and become lodged in key components, thereby rendering them useless. Some of the components include the solenoid valve and the
pressure gauge isolation ball valve.
INCOMING PLUMBING
OUTLET PLUMBING
15
4
9
10
16
1
7
3
2
6
5
4
4
8
9
10
11
10
14
13
17
13
9
18
12
12
10
