Jackson MSC TEMPSTAR - Page 15

Other components not shown:
Cover, Top Mount Control Box 5700-002-23-03
Decal, Warning-Disconnect Power 9905-100-75-93
Screw, 10-32 x 3/8” Phillips Truss Head 5305-173-12-00
Leg, Control Box 5700-002-33-05
Screw, 1/4”-20 x 2 3/4” Hex Head Cap 5305-274-13-00
Washer, 1/4”-20 ID S/S 5311-174-01-00
Locknut, 1/4”-20 S/S Hex w/Nylon Insert 5310-374-01-00
Connector, 1/2”, 90 DEG Plastic 5975-011-45-14
Connector, 3/4”, 45 DEG Plastic 5975-011-47-74
Connector, 1/2”, 45 DEG Plastic 5975-011-45-23
Connector, 1/2”, 90 DEG Metal 5975-111-01-00
Grommet, 1/2” OD x 3/8” ID 5325-011-46-73
Grommet, 7/8” Split 5975-200-40-00
Plug, 1/2” 5975-011-47-81
Decal, Delime/Normal 9905-011-34-96
Decal, L1, L2, L3 9905-101-12-66
Decal, Copper Conductors 9905-011-47-35
Decal, Ground 9905-011-86-86
Associated Hardware:
Locknut, 6-32 S/S Hex w/Nylon Insert 5310-373-03-00
Locknut, 10-24 S/S Hex w/Nylon Insert 5310-373-01-00
Screw, 6-32 x 5/8” 5305-011-39-85
Screw, 6-32 x 3/8” Phillips Round Head 5305-171-02-00
TOP MOUNTED CONTROL BOX ASSEMBLY (CONTINUED)
13
ITEM QTY DESCRIPTION Mfg. No.
1
1 Control Box Weldement 5700-002-29-76
2
1 Ground Lug 5940-200-76-00
3 1 Terminal Block 5940-011-48-27
4 1 Contactor, Wash Motor 208-230 5945-109-03-69
51Relay 5945-111-47-51
6 1 Counter 5990-111-47-42
7
1 Plate, Counter Mounting 5700-002-37-71
8
1 Decal, Control Box 9905-002-31-85
9 1 Light, Yellow 5945-111-44-44
10 1 Light, Green 5945-111-44-43
11 1 Light, Red 5945-111-44-45
12 1 Temperature Gauge, Wash 96" Lead 6685-111-68-48
13 1 Temperature Gauge, Rinse 48" Lead 6685-111-68-49
14 1 Switch, Power 5930-002-29-13
15 1 Timer 5945-303-31-00
16 1 Liquid Level Control Board 6680-200-08-21
17 1 Bracket, Liquid Level Control Board 5700-002-13-22
18 2 Heater Contactors 5945-109-01-69
19 1 Magnetic Reed Switch 5930-011-47-50
20 1 Normal Delime Switch 5930-301-21-18
21 1 Fuse Holder 5920-401-03-14
For a 460 Volt control box, exchange item 4 with one each of the following:
Wash Motor Contactor 5945-002-14-78
Overload 5945-002-14-79
