PERFORMANCE/CAPABILITIES
OPERATING CAPACITY (RACKS/HOUR)
RACKS PER HOUR 57
DISHES PER HOUR 1425
GLASSES PER HOUR 1425
OPERATING CYCLE (SECONDS)
WASH TIME 45
RINSE TIME 11
DWELL TIME 2
TOTAL CYCLE TIME 60
TANK CAPACITY (LITERS) GALLONS
WASH TANK (MINIMUM) 8.0
BOOSTER TANK 3.0
WASH PUMP CAPACITY
(LITERS) GALLONS PER MINUTE 150
TEMPERATURES
WASH---(MINIMUM) 150°F
RINSE---(MINIMUM) 180°F
ELECTRICAL REQUIREMENTS
WASH PUMP MOTOR HP 3/4
WATER REQUIREMENTS
INLET TEMPERATURE (12 KW) (Tempstar) 140°F
INLET TEMPERATURE (14 KW) (Tempstar) 110°F
INLET TEMPERATURE (12 KW) (SDS) 140°F
INLET TEMPERATURE (14 KW) (SDS) 110°F
INLET TEMPERATURE (12 KW) (NB) 180°F
GALLONS PER HOUR 52.0
WATER LINE SIZE I.P.S. (Minimum) 3/4”
DRAIN LINE SIZE I.P.S. (Minimum) 1-1/2”
FLOW PRESSURE P.S.I. (Optimum) 20
FRAME DIMENSIONS
WIDTH 25 3/4”
DEPTH 25 1/4”
HEIGHT 56 3/4”
STANDARD TABLE HEIGHT 34”
MAXIMUM INSIDE CLEARANCE 17 1/4”
RACKS
DISH 20” X 20” OPTIONAL
GLASS & SILVER 20” X 20” OPTIONAL
SPECIFICATIONS for TEMPSTAR/SDS/NB
1
(12 KW Booster Heater) (14 KW Booster Heater)
Model Volts Hz Phase Amps Amps
Tempstar 208 60 1 68.7 75.8
Tempstar 230 60 1 75.4 83.6
Tempstar 208 60 3 42.1 46.3
Tempstar 230 60 3 45.5 50.7
Tempstar 460 60 3 21.7 24.1
Tempstar SDS 208 60 1 68.7 75.8
Tempstar SDS 230 60 1 75.4 83.6
Tempstar SDS 208 60 3 42.1 46.3
Tempstar SDS 230 60 3 45.5 50.7
Tempstar SDS 460 60 3 21.7 24.1
Model Volts Hz Phase Amperage Loads
Tempstar NB 208 60 1 24.6
Tempstar NB 230 60 1 26.6
Tempstar NB 208 60 3 16.3
Tempstar NB 230 60 3 17.5
Tempstar NB 460 60 3 7.9
