Jackson MSC TEMPSTAR - Page 37

TEMPSTAR SDS DISPENSER ASSEMBLY (CONTINUED)
35
ITEM QTY DESCRIPTION Mfg. No.
1 3 Screw, 6-32 x 3/4" Long 5305-171-07-00
2 1 Lockwasher, #6, External Tooth 5311-271-02-00
3 1 Rinse Cylinder Bracket 5700-011-59-72
4 1 Rinse Additive Screen 5930-011-48-66
5 1 Rinse Cylinder Cover 9515-011-49-01
6 1 Rinse Additive Cylinder 9515-031-49-00
7 1 Decal, Rinse Additive 9905-011-59-80
8 1 Rinse Aid Nozzle 4730-011-50-03
9 1 Detergent Screen 5335-011-48-65
10 1 Detergent Spray Nozzle 4730-011-50-04
11 1 Detergent Flush Pipe 5700-011-51-52
12 1 Decal, Detergent Additive 9905-011-59-79
13 3 Light, Red 5945-011-48-96
14 1 Motor, Feeder Pump 6105-111-51-02
15 1 Dispenser Molding 9515-031-48-62
16 1 Sonalert 5945-011-48-97
17
18
19
20
21
23
22
24
25
CAM HOLDER ASSEMBLY
ITEM QTY DESCRIPTION Mfg. No.
17 2 Locknut, 4-40 5310-279-06-00
18 1 Lockwasher, 4-40 5311-011-59-71
19 1 Screw, 4-40 x 3/4" Long 5305-011-59-64
20 1 Spring, .023 Wire 5340-111-58-02
21 1 Magnet, 3/16" x 1" Long Bar 5930-011-48-81
22 1 Holder, Cam Magnet 5340-011-48-80
23 1 Cam Holder 5340-011-59-62
24 1 Switch, 5A 5930-011-48-83
25 2 Screw, 4-40 x 3/8" Long 5305-011-59-70
