Jacobsen ECLIPSE 360 User Manual

B
ADJUSTMENTS
en-87
Safety, Operation, & Maintenance Manual
Lithium
SPECIFIC TORQUE __________________________________________________
Rear Axle Shaft .............150 ft. lbs. (203 Nm)
Tire Lug Nuts.................85-95 ft. lbs (115-128 Nm)
T890 Battery Posts........95-120 in. lbs. (10.7-13.5 Nm)
12 Volt Battery Posts.....80 in. lbs. (9 Nm)
METRIC FASTENERS
SIZE UNITS
Non Critical
Fasteners
into
Aluminum
Lubri-
cated
Dry
Lubri-
cated
Dry
Lubri-
cated
Dry
Lubri-
cated
Dry
M4 Nm (in-
lb)
– – – – – – 3.83 (34) 5.11 (45) 2.0 (18)
M5 Nm (in-
lb)
1.80 (16) 2.40 (21) 4.63 (41) 6.18 (54) 6.63 (59) 8.84 (78) 7.75 (68) 10.3
(910
4.0 (35)
M6 Nm (in-
lb)
3.05 (27) 4.07 (36) 7.87 (69) 10.5 (93) 11.3
(102)
15.0
(133)
13.2
(117)
17.6
(156)
6.8 (60)
M8 Nm (in-
lb)
7.41 (65) 9.98 (88) 19.1 (69) 25.5
(226)
27.3
(241)
36.5
(323)
32.0
(283)
42.6
(377)
17.0 (150)
M10 Nm (ft-
lb)
14.7 (11) 19.6 (14) 37.8 (29) 50.5 (37) 54.1 (40) 72.2 (53) 63.3 (46) 84.4 (62) 33.9 (25)
M12 Nm (ft-
lb)
25.6 (19) 34.1 (25) 66.0 (48) 88.0 (65) 94.5 (70) 125 (92) 110 (81) 147
(108)
61.0 (45)
M14 Nm (ft-
lb)
40.8 (30) 54.3 (40) 105 (77) 140
(103)
150
(110)
200
(147)
175
(129)
234
(172)
94.9 (70)
4.6 8.8 10.9 12.9
