LDU ERROR CODES
en-97
Safety, Operation, & Maintenance Manual
Lithium
5V C Out of Range:
The internal 5V C is out of range.
The valid range is 4.5V to 5.5V.
Analog Supply 1 Out of Range:
The analog supply 1 is out of range.
The valid range is 4.0V to 6.0V.
Analog Supply 2 Out of Range:
The analog supply 2 is out of range.
The valid range is 4.0V to 6.0V.
Ext Gnd Tripped:
The system detected a HW EXT
GND TRIP signal. A reset of the
node is required to clear the error.
Events related to speed feedback
and motor temp measurement may
follow this event.
Motor temperature is above 356° F
(180° C). Shut mower off and wait ten
minutes. Restart mower. If fault
returns, mower must be towed back
to maintenance shed.
    
    
    
Not Connected / Short Circuit:
The motor temperature sensor is
either disconnected or has short
circuited.
LDU Error Code Description
Caution
LED
Alarm
Sound-
ing
Engine
Stop
Traction
Stop
Mow Stop
On Off Yes No Yes No Yes No Yes No
TRACTION
FAULT 3304
3WD TRACTION
FAULT 3304
STEERING
FAULT 3311
STEERING
FAULT 3313
TRACTION
FAULT 3330
STEERING
FAULT 3330
3WD TRACTION
FAULT 3330
TRACTION
FAULT 4210
STEERING
FAULT 4210
3WD TRACTION
FAULT 4210
TRACTION
FAULT 4220
STEERING
FAULT 4220
3WD TRACTION
FAULT 4220
