21
> Change from previous revision
FAIRWAY MOWER
Item Part No. Qty. Description Serial Numbers/Notes
1
502671 1 Reel, 6 Blade Used on 71105
1 502675 1 Reel, 10 Blade Used on 71351
2 121768 1 Bedknife Assembly
3 325163 1 • Bedknife
4 3007308 7 • Screw, 3/8-24 x 3/4” Flat Head
5 445684 7 • Nut, 3/8-24 Marsden
6 315912 2 • Bushing
7 315909 2 Stud, Bedkinfe Mounting
8 447224 2 Washer, 5/8 Shakeproof
9 443828 2 Nut, 5/8-16 Hex Jam
10 500548 2 Handle, Bedknife Adjusting
11 344708 1 • Plug
12 315964 2 Spring, Friction
13 315966 2 Spring, Compression
14 352435 2 Spacer, Bedknife Adjusting
15 315873 2 Washer, Seal
16 315872 2 Seal, Grease
17 315910 1 Spacer Used on Right Side Only
18 500711 2 Bearing, Cup and Cone
19 315877 4 Key, Pinion
20 315843 2 Pinion, Reel
21 306828 2 Washer, Thrust
22 367029 2 Locknut, 3/4-16
23 315965 2 Screw, Bedknife Adjusting
24 315977 2 Bearing, Roller
25 315978 2 Sleeve, Roller Bearing
26 331834 2 Gear, Intermediate
27 3009548 4 Washer, Thrust
To Next Page
