SPECIFICATIONS 4
en-10
4Specifi cations
4.1 ENGINE SPECIFICATIONS __________________________________________________
HR9016T
Make Kubota
Model V3800-DICR-T-E4B
Type Four cycle, liquid cooled, Diesel
Number of Cylinders 4
Bore and Stroke 3.94 in. (10 cm) x 4.72 in. (120 cm)
Total Displacement
230.0 in
3
(3.769 l)
Combustion System Direct Injection
Intake System Turbo Charged
Gross Intermittent Power 99.9 hp (74.5 kW)@2600 rpm
Torque 247.1 ft.Lb. (335 Nm) @1500 rpm
Maximum Speed 2800 ± 50 rpm (No Load)
Low Idle 1100 ± 25 rpm (No Load)
Rotation Counter-clockwise viewed at flywheel
Fuel #2 ultra-low sulfur Diesel fuel
Injection Pump Bosch MD type mini pump
Engine Oil (API Class) CJ-4
Oil Pan Capacity 3.5 gallons (13.25 l)
Starter 12 Volt, 3 kW
Alternator 12 Volt, 60 Amp
Dry Weight 760.6 lb. (345 kg)
Dimensions
(Length x Width x Height)
33.25 x 22.88 x 33.79 in.
(84.37 x 58.11 x 83.46 cm)
Emission Regulation Tier 4i/ Stage IIIB
