2 INTRODUCTION
en-3
2.2 PRODUCT IDENTIFICATION_________________________________________________
Mower Serial number plate
A Gross weight (Kg)
B Engine Power (Kw)
C Date code
D Product number and Serial number
Location of Mower Serial number plate
The serial number plate (A) is found on the left side frame
rail behind the rear decks.
Engine Serial Number
The engine serial number is found on the top of the valve
cover toward the front of the mower. Label shows the engine
group and serial number.
The engine serial number is also found on the engine block.
2.3 SERIAL NUMBERS ________________________________________________________
Record the mower and engine numbers shown below:
Mower Number:_________________________
Engine Number:__________________________
11524 WILMAR BLVD,
CHARLOTTE, NC 28273
®
kg kW
1-800-848-1636 (US)
PRODUCT OF U.S.A.
A Textron Company
ABC
D
105
dB
L
WA
Manufactured under one or more
of the following U.S. patents:
5309699; 5915496; 6,046,530
6336311; 6336312; 7051498
and others pending.
11524 WILMAR BLVD,
CHARLOTTE, NC 28273
®
kg kW
1-800-848-1636 (US)
PRODUCT OF U.S.A.
A Textron Company
xxxx xxxx xxxx
68233001601
A
V2403
S/N KEAXXXXX
Contact KEA for Parts
MADE IN JAPAN
B
B
