4 SPECIFICATIONS
en-15
4.7 SLOPES _________________________________________________________________
DO NOT USE ON SLOPES GREATER THAN TBD°. The 18.6° slope was calculated with static stability measurements
according to the requirements of BS EN ISO 5395-3.
4.8 CUTTING UNIT SPECIFICATION _____________________________________________
4.9 RECOMMENDED LUBRICANTS ______________________________________________
Engine Oil:
Must meet MIL-L-46152 or API Classification grades CJ-4
Hydraulic Fluid:
The standard hydraulic fluid is ISO VG68.
Grease:
Texaco Starplex 2EP Moly (NLGI Grade 2-EP Lithium Complex Grease containing Molybdenum Disulfide) or
equivalent
HR9016T
Blade Length 21 in. (53.3 cm)
Number of blades Front Deck - 5
Left Wing Deck - 3
Right Wing Deck - 3
Height of cut 1 to 5-1/2 in. (2.5 to 14.0 cm)
Height of cut adjustment 1/2 in. (1.3 cm) spacers put on the top of or
below caster wheel housing.
Three position caster wheel mounting.
Clevis pins in various mounting positions.
Blade Tip Speed
@ 2400 rpm engine speed
278.7 feet/second (84.9 meters/second)
Temperature Viscosity
Above 77° F (25° C) SAE 30 or SAE 10W-30 or SAE 10W-40
32° to 77° F (0° to 25° C) SAE 20 or SAE 10W-30 or SAE 10W-40
Below 32° F (0° C) SAE 10W or SAE 10W-30 or SAE 10W-40
