Jacobsen LF 570 Technical/Repair Manual

2-4 4241262-Rev B
SPECIFICATIONS AND GENERAL INFORMATION
2
Specifications
Quick Reference Specifications
Engine
General Engine Specifications
Manufacturer/Models Kubota
®
Interim Tier 4/Stage IIIA
V1505-E3B
Kubota
®
Interim Tier 4/Stage IIIA
V1505-T-E3B
Engine Type 4-Stroke, Diesel
Fuel Requirement No. 2-D Diesel Fuel (Cetane Rating 45)
Number of Cylinders/Configuration 4, In-Line
Displacement
cu in. (cc) 91.41 (1498)
Bore x Stroke
in. (mm) 3.07 x 3.09 (78 x 78.4)
Power Output—V1505-E3B
hp (kW) 35.5 (26.5) @ 3000 rpm
Power Output—V1505-T-E3B
hp (kW) 44.2 (33.0) @ 3000 rpm
Firing Order 1-3-4-2
Compression Ratio 23:1
Injection Timing (Before T.D.C.) 17°
Cooling System Liquid Cooled
Cooling System Capacity—V1505-E3B
(Engine Only)
qt (L) 2.4 (2.3)
Cooling System Capacity—V1505-T-E3B
(Engine Only)
qt (L) 3 (2.8)
Idle Speed 1200 rpm
Maximum Speed (No Load) 3150 rpm
Engine Oil Capacity
qt (L) 7.1 (6.7)
Alternator 12 volt, 40 amp
Dry Weight—V1505-E3B
lb (kg) 242.5 (110.0)
Dry Weight—V1505-T-E3B
lb (kg) 251.3 (114.0)
Repair Specifications
Muffler Tailpipe Mounting Screw lb-ft (N·m) 35–40 (47.5–54.2)
