Jacobsen LF 570 Technical/Repair Manual

SPECIFICATIONS AND GENERAL INFORMATION
4241262-Rev B 2-5
2
Electrical
Test Specifications
Resistance Across Solenoid Coil—
Front Mow Solenoid Coil at 68° F
ohms 5.3 ± 10%
Resistance Across Solenoid Coil—
Front Backlap Coil at 68° F
ohms 5.3 ± 10%
Resistance Across Solenoid Coil—
Rear Mow Solenoid Coil at 68° F
ohms 5.3 ± 10%
Resistance Across Solenoid Coil—
Rear Backlap Coil at 68° F
ohms 5.3 ± 10%
Resistance Across Solenoid Coil—
Raise Solenoid Coil at 68° F
ohms 5.3 ± 10%
Resistance Across Solenoid Coil—
Lower Solenoid Coil at 68° F
ohms 5.3 ± 10%
Resistance Across Solenoid Coil—
Brake Solenoid Coil at 68° F
ohms 9 ± 10%
Resistance Across Solenoid Coil—
Traction Solenoid Coil at 75° F
ohms 23
Resistance Across Fuel Shutoff Pull-In Coil at 68° F
ohm 0.5 ± 10%
Resistance Across Fuel Shutoff Hold-In Coil at 68° F
ohms 15 ± 10%
Traction Pedal Adjustment Value 200–205
Reel Level Proximity Switch Adjustment Lift Arm Angle
degrees 17 ± 1
Reel Level Proximity Switch to Lift Arm Air Gap
in. (mm) 0.118–0.196 (3–5)
Repair Specifications
Solenoid Nut Torque lb-ft (N·m) 10 (13.6)
Brake Solenoid Nut Torque
lb-in. (N·m) 33–53 (4–6)
